定制铝挤压服务
Our Aluminum Extrusion services offer high quality, precision-engineered profiles in numerous applications. Working with prototypes or high-volume production, we can provide you with fast, cost-effective solutions, with tight tolerances, and high material strength.
- Tight Tolerances: Achieve precision profiles with tolerances as tight as ±0.1mm.
- Quick Turnaround: Rapid production of prototypes and low-volume parts, delivered in 5–7 days.
- Certified Quality: ISO 9001:2015, ISO 13485, ISO 16949, and ISO 14001 certified facilities ensure top-tier quality standards.
乐为精密铝挤压服务
在 乐为精密我们提供专业的 定制铝型材服务 我们的产品适用于原型、小批量生产和大规模制造。我们的能力涵盖以下广泛领域 剖面横截面根据您的设计、功能和成本要求，提供量身定制的部件。
我们的挤压车间配备有 70 多条冲压线，从 600 吨到 3800 吨不等因此，我们有能力处理不同形状、复杂程度和数量的项目。每个生产设施都 通过 ISO 9001:2015 认证确保各行业的质量和可靠性保持一致。
Aluminum Extrusion Process & Capabilities at Lewei Precision
Lewei Precision seeks to offer a complete aluminum extrusion procedure aimed at precision, durability, and versatility. Our skilled workforce guarantees quality output in case of custom die production to final finishing of products even after extrusion, applicable in a broad variety of projects. Regardless of your scale of operations, be it the small prototype of extrusions or the big production lines, we provide you with accuracy extrusion.
We have expertise in the manufacturing of both simple and complex extrusion dies, which are accurate and durable to a range of profiles.
The billet preheating process makes our billet precise and the temperature is controlled more precisely to achieve high extrusion consistency which enhances overall performance of a part.
We employ both direct and indirect extrusions, depending on what is the most appropriate to your aluminum profile and design requirements.
Once extruded, parts are cooled and cut to size with high precision to meet your specifications.
Aluminum Extrusion Finishes at Lewei Precision
We provide a range of the finishing types to aluminum extrusions to make them look good, durable, and functional. Finishing solutions that meet the unique requirements of your project are available in any combination of corrosion resistance, professional appearance, and added strength.
Anodized finishes that resist corrosion in various colors, which is suitable where the life and appearance of aluminum parts need to be improved.
Extra strong, durable powder coatings in any color or texture, ideal when a good coating is needed to withstand the outside elements such as extreme wear, corrosion and UV effects.
Electrocoating to increase durability, offer a high level of corrosion resistance and a high quality and smooth surface.
A uniform finish over the parts, with a linear texture that gives a satin effect, which is the best finish to use in both aesthetic and functional purposes.
You require unique finishes that match your specifications and we provide custom finishes that match your specifications in appearance and performance.
It is the perfect finish on steel-related parts; it not only improves the part corrosion resistance but also has a high-quality and professional look.
Aluminum Extrusion Services for Various Industries
In Lewei Precision, we offer aluminum extrusion services to the diverse industries. We work with individual designers, engineers, and manufactures in large scale producing quality and highly engineered aluminum extrusions that fit the precise specifications to the industry.
Aluminum Extrusion vs. CNC Machining vs. Injection Molding
Your project’s complexity, volume, and material requirements will determine the most effective manufacturing method. Below is a comparison to help you choose the right process for your needs.
| VS | 铝挤压 | 数控加工 | 注塑成型 |
|---|---|---|---|
| 模具成本 | Low, requires only a die for extrusion | High, requires specialized tools and setups for each part | High, requires expensive molds (aluminum or steel) |
| 准备时间 | 5–7 days for prototypes and low-volume production | 1–2 weeks, depending on part complexity | 4–12 weeks for mold setup and production |
| 零件数量 | 1–10,000+ parts optimal, scalable for high-volume production | 1–100+ parts, cost increases for larger quantities | 1,000+ parts optimal for mass production |
| 宽容 | ±0.1 mm, high precision for most profiles | ±0.01 mm, very high precision but more time-consuming | ±0.05–0.1 mm, highly accurate for large-volume parts |
| 表面处理 | Variety of finishes, including anodizing and powder coating | Smooth finishes possible, may require post-processing | Smooth, production-ready surface finish |
| 复杂几何 | Great for continuous, complex cross-sections | Excellent for precise, intricate geometries | Limited by mold design, handles undercuts and fine details |
| 材料选择 | Wide range of aluminum alloys for strength and durability | Materials based on machine capabilities (metal, plastic) | Limited to thermoplastics and some elastomers |
| 设计变更 | Easy to implement design changes with minimal cost impact | Challenging to modify, requires new setups and tools | Expensive to modify molds once they are created |
How to Get Started with Aluminum Extrusion
申请报价
Upload your CAD files to receive an immediate, precise quote on an aluminum extrusion project. Our team will study your specifications and make a detailed estimate in a short time.
Die Design Approval
Upon approval of the quote we will work on the die design. You will be able to look at the design and approve before production is done so that it is according to your standards.
生产和交付
When a die is approved we start the extrusion process. Your custom extruded parts will be delivered punctually, to the highest quality requirements, to carry you into the next stage of production.
Certified Quality Control and Testing at Lewei Precision
In Lewei Precision, precision and quality is a core principle throughout the aluminum extrusion process. We perform the inspection process with high standards by using the latest inspection equipment to provide our parts with the best dimensional accuracy, such as Coordinate Measuring Machines (CMM). Our stringent validation procedure is such that each part has been measured and tested of the required standards such as ISO 2768-mK and ASME Y14.5 which ensures that all your custom extrusions are of the utmost of dimensions and geometric accuracy.
The quality of the surface is also of attention to us in measuring the roughness of the surface of the part, the values of Ra are in the range of 3.2 to 0.8 μm. We also check the thickness of the coating to compare the quality of the coating during production. So that we offer transparency and traceability, we keep excellent documentation, such as certificates of materials used and comprehensive inspection reports, such that no part can be untraceable and that each part is manufactured to your precise requirements with the confidence of having the correct one.
订购铝挤压型材
对于需要 基本形状、强度和成本效益标准挤压铝型材是最实用的选择。在 乐为精密我们提供各种常用铝型材，为您的通用项目提供经济可靠的解决方案。
- 铝扁条
- 铝质 G 型材
- 挤压铝槽
- 铝质工字钢
- Y 型铝型材
- 椭圆形铝型材
- 方形铝型材
当标准铝型材无法满足您的设计或性能需求时，Lewei Precision 的定制型材就能满足您的需求。我们提供标准和完全定制的型材，以实惠的价格和可靠的质量支持各行各业。
我们的工程师会审核您的图纸，验证可行性，并选择最有效的工艺，确保高精度和短交货期。
- 附件和连接器
- 建筑结构型材
- 铝槽
- T 型槽轮廓
定制铝挤压材料
我们提供一系列 铝合金每种材料都是根据强度、可加工性、耐腐蚀性和表面处理性能而选择的。
坚固、耐腐蚀、易于加工或焊接。广泛用于结构、机械和汽车零件。
中等强度，表面光滑，非常适合阳极氧化/粉末喷涂。是门窗等建筑型材的理想材料。
具有高耐腐蚀性和导电性的商业纯铝。常用于化工设备、电气部件和食品加工。
铝挤压饰面
质量值得信赖
在乐威精密，质量贯穿于铝挤压工艺的每一个步骤。我们拥有 ISO 认证的设施和 70 多台专用挤压和检测设备，确保每一个型材都符合最高的精度和光洁度标准。
尺寸和公差检查
我们测量关键尺寸，包括横截面宽度、高度、壁厚、总长度、直线度、平面度和垂直度。我们使用卡尺、千分尺、量规和坐标测量机等工具，确保符合您的精确规格。
表面检测
每个型材都要接受划痕、凹痕、裂缝、气泡、毛刺、挤压线和变形的检查。使用高分辨率照明和放大镜可以检测到最细微的表面缺陷。
材料和性能测试
我们可根据要求提供详细的强度和硬度测试结果，以及 RoHS 报告和完整的材料认证，以满足您的项目要求。
为何选择乐为精密铝挤压服务
有多种合金、表面处理、形状和颜色可供选择。每种挤压产品都能满足您的设计、行业标准和性能需求。
我们认为关键维度是 ±0.1毫米 和标准尺寸，以 ±0.15毫米确保始终如一的匹配性、功能性和长期可靠性。
我们的简化流程可确保 7 天内完成标准剖面图而复杂的几何形状可在 10-15 天 - 而不会造成不必要的工具延误。
什么是铝挤压工艺？
铝挤压是将加热后的铝坯料通过模具挤压成型，形成具有特定截面的型材。
在 乐为精密我们遵循成熟的生产工作流程：
- 模具准备 - 为实心、空心或半空心型材加工定制模具。
- 钢坯预热和挤压 - 钢坯加热到 400-500°C 后，根据合金和应用情况，采用直接或间接方法进行挤压。
- 冷却和拉伸 - 型材经过冷却、对齐并切割成精确的长度。
- 老化和抛光 - 热处理增强了强度，而表面处理则增加了防腐蚀性能和视觉吸引力。
- 检验与包装 - 每台挤压机在交付前都要经过严格的尺寸、表面和材料检查。
该工艺可确保乐威精密生产的每件铝型材均符合以下标准 高性能标准 结构完整性、外观和耐用性。
铝挤压的应用
铝型材的强度重量比、耐用性和设计灵活性使全球各行各业都依赖于铝型材。在乐威精密，我们定制的铝型材广泛应用于以下领域
机架、自动化系统、模块化工作站
汽车车架、拖车和火车车身部件
窗户、门、幕墙、外墙、扶手
太阳能电池板框架、风力涡轮机部件、海上结构
外壳、LED 外壳和高效散热器
铝挤压的优缺点
高强度重量比降低了总负载
天然氧化层可防止生锈和退化
100% 可回收材料支持可持续发展目标
T 型槽兼容性和简单的连接方法
只需一道挤压工序就能挤出复杂的型材
与实心铝块相比，加工成本更低
模具制造需要预先 挤出生产线可能需要精加工或抛光
高热时机械强度降低
设计变更需要新的工具
设置和修剪产生废料
压机能力限制了最大型材尺寸
Why Choose Lewei Precision for Aluminum Extrusions?
At Lewei Precision, we offer the highly quality custom extrusion of aluminum in a form of extrusion that suits your demands. Regardless of prototype requirements or high volume production, our aluminum extrusions are available with high levels of accuracy, quick turn-around, and material freedom. We believe in quality and with our experience, we are able to deliver your project with the desired excellence within the least duration.
Precision Engineering
The Lewei Precision extrusion of aluminum is capable of performing to a tight tolerance of +/- 0.1mm and delivers high quality functional parts to any process.
Get prototypes and low-volume parts delivered within 5-7 days, and keep your project on schedule, and meet your deadlines
We are expert at producing bespoke aluminum profiles having complex geometries and cross-sections, suitable in complex designs.
如何制造挤压铝材
铝挤压是一种 多步骤精密加工 将原材料坯料转化为高性能型材。
常见问题
1. What is aluminum extrusion?
Aluminum extrusion is a production process in which heated aluminum is forced through a custom die into producing parts with a specific cross-sectional shape. It is applied to make long aluminum profile in different industries.
2. What is the duration of the extrusion process of aluminum?
It is estimated that the lead time of extrusion of aluminum is 5-7 days when designing prototypes and lower volume production. The bigger production quantities can be more time consuming, based on part and quantity complications.
3. What are the possible materials to be used in aluminum extrusion?
Our extrusion products come in various aluminum alloys comprising of 6061, 6063 and custom alloys. This is because each alloy chosen will depend on the strength, corrosion resistance, and applicability of alloy to your particular application.
4. Is it possible to make custom shapes on the extrusion of aluminum?
Yes, we can make custom profiles of complicated geometry using aluminum extrusion, solid profiles, hollow profiles, or multi-chambered sections. We have the capacity to handle special design requirements according to the project requirements.
5. What industries are capable of utilizing the services of aluminum extrusion?
Automobiles, aerospace, construction, medical equipment, electronics and others are some of the industries where aluminum is used in extrusion. It is employed in the production of structural frames, heat sink and ornamental trims.
6. What are the tolerances of aluminum extrusions?
We have a standard tolerance of aluminum extrusions of ±0.1mm which is very precise on parts. Specific requirements can be tolerated more strictly.
7. What is the advantage of aluminum extrusion over other processes, such as die casting or CNC machining?
Aluminum extrusion is cost effective in high volume production, has better strength to weight ratio and more design capability than die casting and CNC machining, particularly in complex continuous profiles.
8. How do I obtain a quote of my aluminum extrusion project?
In order to receive a quote, you only have to upload your CAD files on our site. We will assess your design and offer you an elaborate design estimate depending on your specifications and needs.
9. Is it possible to change my design once extrusion process has begun?
The design could be changed at the early stages of the project, which might cost some extra money and time. The best thing is to design last and production first so that you can be in time, and at a reasonable cost.
10. What do you do to guarantee the quality of aluminum extrusions?
The high-level inspection procedures such as CMM ( Coordinate Measuring Machines ) are in use to ascertain dimensional accuracy, and a surface finish test and coating validation are in use to ascertain high quality results throughout production.
